Color: Black

Size and Weight

Height: 164.8 mm

Width: 79.2 mm

Depth: 18.15 mm

Weight: 381.4 grams

*Size and weight vary by configuration and manufacturing process. Actual measurements between individual products may vary. All specifications are subject to the actual product.

Walkie-talkie

Digital-analog Intercom

Frequency Range: 400MHz-480MHz

Transmitted Power: 1W-2W

Intercom Channel: 136

Signal Distance

Charging and battery

10850mAh Battery

Built-in lithium-ion polymer battery

USB Type-C port

Supports 33W super fast charging

Battery Life

*Typical value. Actual capacity may vary slightly. This capacity is the nominal battery capacity. The actual battery capacity for each individual product may be slightly above or below the nominal battery capacity.

*Non-removable battery. Removing the battery may cause damage to the device.

*Use with original charger and data cable, the max charging power can reach 33W. The actual charging power will intelligently change with different scenarios, please refer to the actual use.

Rugged

Splash, Water and Dust Resistant

Rated IP68 (maximum depth of 1.5 metres up to 30 minutes) under IEC standard 60529

Rated IP69K under IEC standard 60529

MIL-STD-810H Certification

*Armor 20WT is splash, water, and dust resistant and was tested under controlled laboratory conditions with a rating of IP68 under IEC standard 60529 (maximum depth of 1.5 meters up to 30 minutes). Charger and accessories are not water-resistant. Splash, water and dust resistance are not permanent and might decrease as a result of normal wear. Do not attempt to charge a wet Armor 20WT. Liquid damage not covered under warranty.

Processor

MediaTek Helio G99

CPU: MediaTek MT6789

CPU architecture: 2*Cortex-A76+6*Cortex-A55, 6nm process

CPU frequency: Octa Core, up to 2.2GHz

GPU: Arm Mali-G57 MC2
GPU frequency: up to 1GHz

Storage and RAM

12GB+256GB

RAM: 12GB large memory

Flash storage: 256GB phone storage

microSD memory card Up to 2TB

*Available storage and RAM are less than the total memory due to storage of the operating system and software pre-installed in the device.

*The Virtual Memory Expansion can be activated in Settings and adds up to 8GB of RAM. Some software may not be compatible with this feature.

*microSD card needs to be purchased separately. Recommended to use Class 10 memory cards, other memory cards are not guaranteed to be fully compatible.

Display

5.65‑inch (diagonal)

All-screen LCD Multi-Touch display with IPS technology
Incell technology

Resolution: 2160 x 1080 FHD+ 424 PPI

Corning Gorilla Glass (1.1mm thickness)

Fingerprint-resistant oleophobic coating

*With a rounded corners design on the display, the diagonal length of the screen is 5.65 inches when measured according to the standard rectangle (the actual viewable area is slightly smaller).

*The resolution measured as a standard rectangle, with a rounded corners design, the effective pixels are slightly less.

Rear Camera

50MP Rear Camera

50MP Ultra High-Resolution Primary Camera

Samsung JN1 sensor, 1.0µm, 5 piece lens

FOV 79.2°, ƒ/1.8 large aperture

Photo resolution: up to 6096 x 8128 pixels

Video resolution: up to 2K

Dual LED Flash

Rear camera photography features

Custom, Picture size, Location info, Brand watermark, Camera Mute, Touch shooting, Self timer, Grid line, Volume key feature, Anti flicker, Reset
Normal mode, Night mode, Portrait, Gif, Pro Mode, Panorama, Slow Motion, Time Lapse, Intelligent Scanning

Rear camera video features

*The depth sensor can only be used as a photography assistant to improve the photo effect and needs to be used with other cameras for imaging.

*The actual photo and video resolution may vary depending on the shooting mode.

*The camera software functions are subject to actual presence, some functions and names may vary depending on the software version.

Front Camera

16MP selfie camera

SONY IMX481 Sensor, 1.0µm,  5 piece lens

FOV 81°, ƒ/2.2 large aperture

Front camera photography features

Custom, Picture size, Location info, Brand watermark, Mirror, Camera Mute, Touch Shooting, Self timer, Grid line, Volume key feature, Reset

Normal mode, Night mode, Portrait, Gif, Pro Mode, Panorama, Slow Motion, Time Lapse, Intelligent Scanning

Front camera video features

*The camera software functions are subject to actual presence, some functions and names may vary depending on the software version.

Underwater Photography

Supports to take photos & video recording

Supports to start/end operation underwater

Supports to quickly switch shooting modes underwater

Unlock Options

Supports Fingerprint Unlock

Side-Mounted Fingerprint, Integrate power key and fingerprint sensor together

Capacitive Touch Sensor

Response speed: Up to 0.1s

Supports the enrollment of 5 sets of fingerprint

Supports Face Unlock

Network

Supports use of dual SIM cards from different carriers

Both cards can access 4G connectivity simultaneously

Dual Nano SIM; either card can be set as the primary card

Supports 4G/3G/2G

Supports VoLTE HD calling

Supported network bands

4G Network

LTE-FDD: B1/2/3/4/5/7/8/12/13/17/18/19/20
25/26/28A/28B/66

LTE-TDD: B34/38/39/40/41

3G Network

WCDMA: B1/2/4/5/6/8/19

2G Network

GSM: B2/3/5/8

CDMA: 1X(BC0/BC1)

*Dual 4G SIM requires the support of local telecom operator services, and may not be available in all regions.

*Only certain regions and telecom operators support VoLTE.

Connectivity

WLAN

Supports protocols: 802.11 a/ac/b/g/n

Supports 2.4G Wi-Fi / 5G Wi-Fi

Bluetooth

Supports Bluetooth 5.2

Navigation and positioning

Supports multiple positioning systems

GPS

GLONASS

Galileo

BEIDOU

Supports Digital Compass
